Specifications:
1). Transparent color

2). Meet or exceed the requirement in the cat5e T568A and T568B

3). Contacts are nickel plated, phosphor bronze with 1U, 3U, 6U….50U gold plated

4). Exclusive stagger conductors guide design reduces near end cross talk

6) Accept 22AWG, 23AWG, 24AWG, 26AWG solid with a insulation diameter of 0.64mm, 0.56mm, 0.50mm, 0.40mm

Electrical:

1) UL application:250vac,2a(max)

2) Dielectrical with standing voltage:500v AC

3)insulation resistance:35m ohm(max), after environmental testing

Mechanical:

1 )cable- to-plug tensile strength:20lbs(89n) (min.)

2)Durability: 750 matching cycles

3) temperature range:-40~60

Material and finish:

1) housing:polycarbonate(pc)UL94-v-0 or UL 94-v-2
2) contact blade: phosphor broze
3) Gold plating:copper with nickel,3-50u gold plating
