| Model NO: | Fiber Optical Patch Cord | Connetcor:: | LC/SC/FC/ST |
|---|---|---|---|
| Connector Type: | SC-SC LC-LC FC-FC ST-ST Or Hybrid | Length: | 1m 2m 3m Or Customized |
| Material:: | PVC/LSZH | Application: | FTTH/Test Equipments/TV/LAN/Telecommunication Equipments |
| Color: | Yellow,Orange Or Others,aqua Or Cusomized | Return Loss: | >30dB |
| High Light: | ETL Optical Fiber Patch Cord,3m Optical Fiber Patch Cord,3m fiber optic patch cable | ||
OPTICAL FIBER PATCH CORD SC/UPC-ST/UPC-SM-DUPLEX Jumper Cable sc pc fiber optic patch cable
Applications
1.Local Area Network (LAN)
2.Data communication network
3.Telecommunication optical transmission network
4.Optical access network(OAN)
5.Active device termination
6.Fiber optics data transmission(FODT)
7.Test Equipment
8.CATV
Features
1.Low insertion loss and hight return loss.
2.Excellent repeatability and changeability
3.Simplex and duplex available.
4.With ceramic fettules.
5.PVC&LSNH cable option.
6.Optical performance 100% factory test.
Specification:
| Item | Single Mode | Multi Mode |
| Insertion Loss | <=0.2dB | <=0.3dB |
| Return Loss | PC≥50dB,UPC≥55dB,APC≥60dB | |
| Insert-pull Test | 1000 times | |
| Repeatability | ≤0.1 | |
| Tensile strength | ≥10KG | |
| Operating Temperature | -40℃~+85℃ | |
| Ceramic Ferrule Specification | 125.5um concentricity deviations:≤1um | 127um concentricity deviation:≤3um |
| Suitable Fiber | 9/125um | 50/125um,62.5/125um |
Performance Index:
| Item | SM(Single Mode) | <span style="margin: 0px; padding: 0px; border: 0px currentColor; border-image: none; | |||
