| Model NO: | Fiber Optical Patch Cord | Connector Type: | SC-SC LC-LC FC-FC ST-ST Or Hybrid |
|---|---|---|---|
| Length: | 1m 2m 3m Or Customized | Material:: | PVC/LSZH |
| Color: | Yellow,Orange Or Others,aqua Or Cusomized | Real Factory: | Yes |
| Fiber Type: | G652D,G655 | Quality Control: | 100% Test Before Shipping |
| High Light: | 3m LCAPC simplex patch cord,UL certified 3m simplex patch cord,UL certified 3m single mode fiber patch cord | ||
LSZH PVC Jacket 3 Meters LCAPC Single Mode Simplex Fiber Optic Patch Cord
Product Description
SC cable assemblies are designed for the most advanced fiber optic systems providing exceptional stability and low reflection (single-mode). SC cable assemblies are well suited for high-density applications. The SC connector uses a rectangular, molded design for quick, easy push-pull installation. This design prevents ferrule rotation and axial damage on the fiber contact points, reducing the potential for damage from mechanical vibration.
Features:
· Low insertion loss and high return loss
· The patch cord can be customized according to customer’s specific requirements
· Strict quality testing: IL and RL 100% test.
· All materials meet the RoHS standard.
Applications
· Optical fiber communication system
· telecommunication network
· LANs and WANs
· CATV
· FTTX
Specifications:
| Item | Parameter | |
| connector type | SC, LC, FC, ST, MU, D4, DIN | |
| Fiber mode | Single mode | Multi-mode |
| Operating wavelength | 1250~1650nm | 850nm, 1300nm |
| Test wavelength | 1310nm, 1550nm | 850nm, 1300nm |
| Insertion Loss | Typ ≤0.20dB<font sty | |
